Diamond Systems
PCIe MiniCard Carrier
Description
The PCIe MiniCard carrier offers four PCIe MiniCard sockets on a compact PCI/104 Express form factor board. All four sockets have PCIe x 1 and USB interfaces and support full size and half size PCIe MiniCard modules.
The module provides full support to all sockets while consuming only a single lane of host SBC resources. SIM card support is provided for two sockets.
All power is derived from the PCIe/104 connector +5V power tab. The PCI-104 connector provides a pass through connection and is not used by the module.
Rugged Design
Extended temperature capability (-40°C to +85°C) enables the board to operate in environments with extreme temperature swings, such as vehicles or outdoor installations. For further enhanced ruggedness, zero ohm resistors can replace jumpers.
Diamond Systems
Diamond Systems Corporation on Ameerika ettevõte, mille peakontor asub Sunnyvales, Californias. Alates 1989. aastast on ettevõte spetsialiseerunud vastupidavatele ja I/O-rikastele manussüsteemidele.
Ettevõte pakub laia valikut tooteid, sealhulgas üheplaadilisi arvuteid (SBC), I/O-laiendusmooduleid, Ethernet-lüliteid ja toiteplokke, mis on loodud töötama rasketes tingimustes.
Diamond Systemsi tooteid kasutatakse paljudes valdkondades, sealhulgas transpordis, energeetikas, lennunduses, kaitses, tootmises, meditsiinis ja teadusuuringutes. Ettevõte on tuntud oma uuendusliku lähenemise poolest standarditele nagu PC/104 ja COM Express ning kohandatud lahenduste pakkumise poolest.
Tooted on välja töötatud taluma ekstreemseid temperatuure, vibratsioone ja muid keerulisi tingimusi, sobides hästi sõjaväesõidukite ja tööstusautomaatika rakenduste jaoks.
Loe rohkem: Diamond Systems
-
-
