Mounting, Heatsink & DIN adaptor option

Mounting Kits: 1LK00100: Mounting SC-SO-SF on heatsink or SC-SO on 1LD12020. 1LK00200: Mounting SG-SVT-SV9 on heatsink or 1LD00000. 1LK00300: Mounting heatsinks on 1LD00400 or SC-SO on 1LD00000. 1LK00700: Special kit for high current (okpac range). Thermal Seals Relay/Heatsink. 5HT15000: Thermal grease fo 30 relays SG/SVT ou 60 relays SC/SO. 5TH21000: Thermal precut film for SC/SO. 5TH23000: Thermal pads. WF031100: Terminal characteristics: 0,3K/W. Specifications: ventilated for DIN rail or screw. Dimensions (mm): 110x120x145. Relay type: SO, SC, SG, SGT, SVT. WF050000: Terminal characteristics: 0,55K/W. Specifications: DIN rail adaptor as option. Dimensions (mm): 110x100x200. Relay type: SO, SC, SG, SGT, SVT. WF070000: Terminal characteristics: 0,75K/W. Specifications: DIN rail adaptor as option. Dimensions (mm): 110x100x100. Relay type: SO, SC, SG, SGT, SVT. WF115100: Terminal characteristics: 0,9K/W. Specifications: for DIN rail or screw. Dimensions (mm): 110x100x90. Relay type: SO, SC, SG, SGT, SVT. WF108110: Terminal characteristics: 1,1K/W. Specifications: FOR DIN rail or screw. Dimensions (mm): 89,8X81X98,02. Relay type: SO, SC. WF121000: Terminal characteristics: 1,2K/W. Specifications: for DIN rail or screw. Dimensions (mm): 110x40x100. Relay type: SO, SC, SG, SGT, SVT. WF210000: Terminal characteristics: 2,1K/W. Specifications: DIN rail adaptor as option. Dimensions (mm): 96X41X55. Relay type: SO, SC. WF151200: Terminal characteristics: 2,2K/W. Specifications: for DIN rail or screw. Dimensions (mm): 45X73X80. Relay type: SO, SC, SA, SU. WF311100: Terminal characteristics: 3K/W. Specifications: for DIN rail or screw. Dimensions (mm): 22,5X73X80. Relay type: SA, SU.
