HDMI-LPC / LPM HDMI sliprings

HDMI is a proprietary audio/video interface for transmitting uncompressed video data and compressed or uncompressed digital audio data from an HDMI-compliant source device to a compatible computer monitor, video projector, digital television, or digital audio device. The HDMI slip rings made by JINPAT is reliable to allow transfer of HDMI1.4(10.2Gbps) from a stationary to a rotating structure. Our design is available with multiple HDMI channels, power and signal integration within one slip ring. What’s more, the innovative designs meet the demanding requirements on crosstalk, insertion loss and return loss to control noise ratio and ensure transmission stability. As the leading slip ring manufacturer in China and aiming to be one of the top manufacturer over the world, JINPAT has never stopped to develop HDMI slip rings for the latest commercial, surveillance, VR or other entertainment applications. To respond to the rising market for HDMI slip ring solutions, JINPAT has developed a broad range of HDMI products with combinations of data and power in multiple mechanical configurations to meet your application needs.

Manufacturer

Jinpat

Circuits

10

IP code rating

IP54

Material

Aluminum

Max operating speed

300 rpm

Fieldbus/Interface

HDMI; USB; Signal; Current; Ethernet

Product sheet

Jinpat


Founded in 1996 Jinpat Electronics is an experienced leader among slip ring companies worldwide.
The slip ring and rotary joint specialist with the broadest range. Manufacturing various industrial slip rings for industrial machinery, surveillance and radar systems, automation, artificial intelligence, aircraft, medical devices, marine equipment, defence, e t c.
With over two decades of research and production experiences, Jinpat collaborated and established strong relationships with multinational companies, research institutions, military departments, prestigious universities, e t c.
In addition, Jinpat provide both standard products and customizations. All products are secured by the quality management system certified by ISO9001:2008.
